PixelCrushers.DialogueSystem.Wrappers.DialogueSystemTrigger Class Reference

This wrapper class keeps references intact if you switch between the compiled assembly and source code versions of the original class. More...

Inheritance diagram for PixelCrushers.DialogueSystem.Wrappers.DialogueSystemTrigger:

Collaboration diagram for PixelCrushers.DialogueSystem.Wrappers.DialogueSystemTrigger:

Additional Inherited Members
Public Types inherited from PixelCrushers.DialogueSystem.DialogueSystemTrigger
enum	BarkSource { None , Conversation , Text }
Public Member Functions inherited from PixelCrushers.DialogueSystem.DialogueSystemTrigger
virtual void	Awake ()
virtual void	Start ()
void	OnBarkStart (Transform actor)
void	OnBarkEnd (Transform actor)
void	OnConversationStart (Transform actor)
void	OnConversationEnd (Transform actor)
void	OnSequenceStart (Transform actor)
void	OnSequenceEnd (Transform actor)
void	OnSequenceEnd ()
void	OnUse (Transform actor)
void	OnUse (string message)
void	OnUse ()
void	OnTriggerEnter (Collider other)
void	OnTriggerExit (Collider other)
void	OnTriggerEnter2D (Collider2D other)
void	OnTriggerExit2D (Collider2D other)
void	OnCollisionEnter2D (Collision2D collision)
void	OnCollisionExit2D (Collision2D collision)
void	OnCollisionEnter (Collision collision)
void	OnCollisionExit (Collision collision)
void	OnEnable ()
void	OnDisable ()
void	OnLevelWillBeUnloaded ()
void	OnApplicationQuit ()
void	OnDestroy ()
void	TryStart (Transform actor)
virtual void	TryStart (Transform actor, Transform interactor)
	Sets the quest status if the condition is true.
virtual void	Fire (Transform actor)
void	ResetBarkHistory ()
	Resets the bark history to the beginning of the list of bark lines.
void	OnRecordPersistentData ()
	Listens for the OnRecordPersistentData message and records the current bark index.
void	OnApplyPersistentData ()
	Listens for the OnApplyPersistentData message and retrieves the current bark index.
Public Attributes inherited from PixelCrushers.DialogueSystem.DialogueSystemTrigger
DialogueSystemTriggerEvent	trigger = DialogueSystemTriggerEvent.OnUse
	The trigger that this component listens for.
Condition	condition
	The conditions under which the trigger will fire.
bool	setQuestState = true
	If true, set the quest state.
string	questName
	The name of the quest.
QuestState	questState
	The new state of the quest when triggered.
bool	setQuestEntryState = false
	If true, set the quest entry state.
int	questEntryNumber = 1
	The quest entry number whose state to change.
QuestState	questEntryState
	The new state of the quest entry when triggered.
bool	setAnotherQuestEntryState = false
int	anotherQuestEntryNumber = 1
QuestState	anotherQuestEntryState
string	luaCode = string.Empty
	The lua code to run.
string	sequence = string.Empty
Transform	sequenceSpeaker
	The speaker to use for the sequence (or null if no speaker is needed).
Transform	sequenceListener
	The listener to use for the sequence (or null if no listener is needed).
bool	waitOneFrameOnStartOrEnable = true
string	alertMessage
	An optional gameplay alert message.
TextTable	textTable
	An optional localized text table to use for the alert message.
float	alertDuration = 0
SendMessageAction[]	sendMessages = new SendMessageAction[0]
	Targets and messages to send when the trigger fires.
BarkSource	barkSource = BarkSource.None
string	barkConversation = string.Empty
	The title of the bark conversation.
int	barkEntryID = -1
	Dialogue entry to bark.
string	barkEntryTitle
	Bark entry with this Title.
string	barkText = string.Empty
	Text to bark.
string	barkTextSequence = string.Empty
	Optional sequence to play when barking text.
Transform	barker
	The barker.
Transform	barkTarget
	The target of the bark.
BarkOrder	barkOrder = BarkOrder.Random
	Specifies the order to run through the list of barks.
bool	allowBarksDuringConversations = false
	Are barks allowed during conversations?
bool	skipBarkIfNoValidEntries
	Skip bark if no valid entries.
bool	cacheBarkLines = false
	If ticked, bark info is cached during the first bark.
string	conversation = string.Empty
	The title of the conversation to start.
Transform	conversationConversant
	The conversant of the conversation.
Transform	conversationActor
	The actor to converse with.
int	startConversationEntryID = -1
string	startConversationEntryTitle
GameObject	overrideDialogueUI = null
bool	exclusive = false
	Only start if no other conversation is active.
bool	replace = false
	Stop other conversation if one is active.
bool	queue = false
	If another conversation is active and simultaneous conversations aren't allowed, queue this conversation to start as soon as active one ends.
bool	skipIfNoValidEntries = false
	If this is true and no valid entries currently link from the start entry, don't start the conversation.
bool	preventRestartOnSameFrameEnded = false
bool	stopConversationOnTriggerExit = false
	Set true to stop the conversation if the actor leaves the trigger area.
float	marginToAllowTriggerExit = 0.2f
bool	stopConversationIfTooFar = false
float	maxConversationDistance = 5f
float	monitorConversationDistanceFrequency = 1f
bool	showCursorDuringConversation = false
bool	pauseGameDuringConversation = false
SetGameObjectActiveAction[]	setActiveActions = new SetGameObjectActiveAction[0]
SetComponentEnabledAction[]	setEnabledActions = new SetComponentEnabledAction[0]
SetAnimatorStateAction[]	setAnimatorStateActions = new SetAnimatorStateAction[0]
GameObjectUnityEvent	onExecute = new GameObjectUnityEvent()
bool	useConversationTitlePicker = true
bool	useBarkTitlePicker = true
bool	useQuestNamePicker = true
DialogueDatabase	selectedDatabase = null
Protected Member Functions inherited from PixelCrushers.DialogueSystem.DialogueSystemTrigger
IEnumerator	ShowCursorAfterOneFrame ()
void	CheckOnTriggerExit (Transform otherTransform)
IEnumerator	StartAtEndOfFrame ()
virtual void	OnSaveDataApplied ()
virtual IEnumerator	FireIfNoSaveDataApplied ()
virtual void	DoQuestAction ()
virtual void	DoLuaAction (Transform actor)
virtual void	DoLuaAction ()
virtual void	DoSequenceAction (Transform actor)
virtual void	DoAlertAction ()
virtual void	DoSendMessageActions ()
virtual void	DoBarkAction (Transform actor)
virtual Transform	GetBarker (string conversation)
virtual string	GetBarkerName ()
virtual void	BarkCachedLine (Transform speaker, Transform listener)
void	PopulateCache (Transform speaker, Transform listener)
void	BarkNextCachedLine (Transform speaker, Transform listener)
virtual void	DoConversationAction (Transform actor)
virtual void	StopActiveConversation ()
void	StopMonitoringConversationDistance ()
IEnumerator	MonitorDistance (Transform actor)
virtual void	DoSetActiveActions (Transform actor)
virtual void	DoSetEnabledActions (Transform actor)
virtual void	DoSetAnimatorStateActions (Transform actor)
Protected Attributes inherited from PixelCrushers.DialogueSystem.DialogueSystemTrigger
BarkHistory	barkHistory
ConversationState	cachedState = null
BarkGroupMember	barkGroupMember = null
IBarkUI	barkUI = null
bool	isConversationQueued = false
Transform	queuedActor = null
float	earliestTimeToAllowTriggerExit = 0
Coroutine	monitorDistanceCoroutine = null
bool	wasCursorVisible
CursorLockMode	savedLockState
bool	didIPause = false
float	preConversationTimeScale = 1
int	frameConversationEnded = -1
bool	tryingToStart = false
bool	hasSaveSystem
Coroutine	fireIfNoSaveDataAppliedCoroutine = null
ActiveConversationRecord	activeConversation
bool	listenForOnDestroy = false
Properties inherited from PixelCrushers.DialogueSystem.DialogueSystemTrigger
Sequencer	sequencer [get, protected set]
	Gets the sequencer used by the current bark, if a bark is playing.
BarkHistory	BarkHistory [get]

Detailed Description

This wrapper class keeps references intact if you switch between the compiled assembly and source code versions of the original class.

---

The documentation for this class was generated from the following file:

• C:/Dev/Dialogue System/Dev/Release2/Assets/Plugins/Pixel Crushers/Dialogue System/Wrappers/Triggers/Trigger/DialogueSystemTrigger.cs
